The UDI-ready rotary sealing system hm 5000 DC-VI PrintPak med has been developed for the special requirements of the medical and pharmaceutical industry.
With PrintPak med you are perfectly prepared for the future of UDI medical device labelling. The unique product identifier (UDI) by means of a numeric or alphanumeric code enables a unique identification of medical devices on the market, facilitates their traceability, prevents plagiarism and thus improves overall patient safety. The hm 5000 DC-VI PrintPak med rotary sealer with integrated inkjet print probe combines all UDI-relevant data in a matrix code and prints it directly onto the clear side of the sterile barrier system.
PrintPak med enables flexible data entry by means of a keyboard, network, 2-D Scanner, RFID Reader and matrix reader.
The integrated InkJet print probe ensures a razorsharp print image directly on the transparent side of the sterile barrier system. A fast-drying ink prevents smudging of the print image and ensures the permanent readability of the matrix code.
Due to the innovative DocLink communication unit the hm 5000 DC-VI PrintPak med can easily be linked to batch documentation and tracking systems. It is equipped with four USB A and one RS 232 interfaces. An additional Ethernet interface makes the hm 5000 DC-VI PrintPak med network-compatible.
The hm 5000 DC-VI PrintPak med is equipped with the new hawo TraceLog technology. All actions are recorded and can be viewed if required. If the DataMatic function is activated via a connected USB stick, each action is automatically copied and can then be viewed in a spreadsheet program (e.g. Excel). All data can also be exported via the integrated Ethernet port.
A 7” TFT touch screen and an intelligent controller in connection with the AppCtrl applications allowing to call up device and programming functions, make operation and validation even more comfortable and easy. The main screen can be adapted individually by the user according to his needs. The hm 5000 DC-VI PrintPak med is equipped with a HDMI port and can be connected to any commercially available monitor or TV.
For the sealing seam, the proven SealPeak technology is used. Hawo SealPeak sealing seams are 12 mm (0,5 inch) wide, flat seams with a so-called barrier of extremely high solidity at their centre. The seal strength increases steadily from the edges towards the SealPeak. The advantage of these soft edges is that the product cannot break through the edges, but gently pierces them and is then caught by the SealPeak at the centre. SealPeak sealing seams also have excellent peeling properties without paper shredding, even if the user peels the pack open in the wrong direction. Of course, the hm 5000 DC-VI PrintPak med is suitable for sealing all common sealable pre-made sterile barrier systems and medical packaging as well as uncoated Tyvek® and polyolefin packaging. Modified seam structures can be offered on request.
Environmental protection and sustainability are not ends in themselves. The hm 5000 DC-VI PrintPak med consistently counts on a resource-efficent design with a completely new type of sealing technology, which only needs a fraction of the energy required by similar devices. The heating works with a highly efficient 24 Volt system which reduces the power consumption to a minimum. The stand-by function and automatic shut-down, when not in use, complete hawo‘s GreenTek concept – without compromising the quality of the sealing results!
| SEALING MATERIALS | |
|---|---|
| Sealable paper pouches according to EN ISO 11607-1/EN 868-4 | Yes |
| Sealable pouches and reels according to EN ISO 11607-1/EN 868-5 made of film and paper according to EN 868-3 | Yes |
| Sealable pouches and reels according to ISO EN 11607-1/EN 868-5 made of film and uncoated materials made of polyolefins according to EN 868-9 (e.g. Tyvek®) | Yes |
| Sealable pouches and reels according to ISO 11607-1/EN 868-5 made of PP fleece or PP nonwoven | Yes |
| Peelable pouches PA/PE | Yes |
| Laminated aluminium pouches | Yes |
| TECHNICAL DATA | |
| Validatable process | Yes |
| Microprocessor controlled | Yes |
| Display | 7” TFT graphic colour |
| Input keyboard | touchscreen (external keyboard/mouse optional) |
| Integrated dot-matrix printer (for printing on the back of the SBS) | 24-dot matrix, single lined, for special characters |
| Print height dot-matrix printer | 4 mm (0.16 inch) |
| Integrated InkJet printer (for printing on the clear side of the SBS) | Yes |
| Print height InkJet printer | 12 mm (0.47 inch) |
| RS 232 connection | Yes |
| USB connection | Yes (4x) |
| Ethernet connection | Yes |
| HDMI connection | Yes |
| Sealing speed (dwell) | 5-13 m/min (197-512 inch/min) (monitored) |
| Sealing temperature | max. 210 °C (410 °F) (monitored) |
| Contact pressure | 100 N (factory setting/monitored) |
| Switch-off tolerance | +/- 5°C (DIN 58953-7) |
| Seal distance from the material edge | 0-35 mm (0-1.4 inch) |
| Seal seam width | 12 mm ± 0.5 mm (0.5 inch ± 0.02 inch) |
| Sealing system | UniSeal (knurled seam) |
| Mains connection | 100-240 V, 50/60 Hz |
| Power consumption | 90 W |
| Dimensions (W x D x H) | 730 x 260 x 225 mm (28.7 x 10.2 x 8.9 inch) |
| Weight | 25 kg (55 lb) |
| Housing | stainless steel |
| Cleanroom environment | Testing required |
| ACCESSORIES | |
| hawo scanner | Yes |
| Label printer | Yes |
| Roll conveyor hm 500 RT | Yes |
| Tray hm 1000 T | Yes |
